Descriere
afișaj |
Display resolution | 1024 x 768 pixels |
Display diagonal | 15 " |
Contrast ratio (typical) | 800:1 |
Response time | 8 ms |
Viewing angle, vertical | 176 ° |
Viewing angle, horizontal | 176 ° |
Display technology | LCD |
Pixel pitch | 0.297 x 0.297 mm |
HD type | XGA |
Native aspect ratio | 4:3 |
Panel type | TN |
Viewable size, horizontal | 304.1 mm |
Viewable size, vertical | 228.1 mm |
Digital horizontal frequency | 31 - 60 kHz |
Screen shape | Flat |
Touchscreen technology | Projected capacitive system |
Number of simultaneous touchpoints | 10 |
Touchscreen | Yes |
Touch technology | Multi-touch |
Display brightness (typical) | 350 cd/m² |
Performanță
AMD FreeSync No NVIDIA G-SYNC No
Multimedia
Built-in speaker(s) Yes RMS rated power 2 W Built-in camera No Number of speakers 2
Design
Product colour Black International Protection (IP) code IP54
Conexiune
HDMI ports quantity 1 DisplayPorts quantity 1 HDCP Yes VGA (D-Sub) ports quantity 1 HDMI Yes USB Touch port Yes Built-in USB hub No Headphone out No
Ergonomice
Panel mounting interface 100 x 100 mm VESA mounting Yes Tilt angle range -5 - 90 ° Cable lock slot Yes Cable lock slot type Kensington Height adjustment No Cable management Yes Tilt adjustment Yes
Managementul energiei
Power consumption (typical) 16 W AC input voltage 100 - 240 V Power consumption (standby) 1.5 W AC input frequency 50/60 Hz Energy efficiency class (SDR) E Power consumption (off) 0.3 W Power supply type Internal
Conţinutul de ambalaje
Cables included Audio,DisplayPort,HDMI,Power,USB Quick start guide Yes
Greutate şi dimensiuni
Depth (with stand) 200 mm Width (with stand) 351 mm Height (with stand) 306.5 mm Weight (with stand) 3700 g
Sustenabilitate
European Product Registry for Energy Labelling (EPREL) code 1547232
