Descriere
Scanare |
Scanner type | 1D/2D |
Type | Handheld bar code reader |
2D (matrix & stacked) barcodes supported | Code 39,Data Matrix,PDF417,QR Code |
Linear (1D) barcodes supported | PDF417,UPC-A,UPC-E |
Pitch reading angle | -45 - 45 ° |
Sensor type | LED |
Yaw reading angle | -65 - 65 ° |
Light levels (direct sunlight) | 0 - 100000 lx |
Optical sensor resolution (W x H) | 1280 x 800 pixels |
Conexiune
Standard interfaces Keyboard wedge,RS-232,USB Connectivity technology Wired
Performanță
Product colour Black,Red International Protection (IP) code IP67
Managementul energiei
Input voltage 4 - 5.5 V Power source type Battery,DC Power consumption 2.35 mA Battery type Built-in battery Power consumption (typical) 2.35 W Power consumption (standby) 0.5 W
Greutate şi dimensiuni
Width 100 mm Depth 76 mm Height 192 mm Weight 320 g
Conditii de mediu
Operating temperature (T-T) -30 - 50 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 0 - 95 %
