Descriere
Conexiune |
Ethernet LAN (RJ-45) ports | 2 |
Host interface | PCI Express |
Interface | Ethernet |
Connectivity technology | Wired |
Reţea
Cabling technology 10/100/1000BaseT(X) Jumbo frames support Yes Wake-on-LAN ready Yes Networking standards IEEE 802.3ad,IEEE 802.3q,IEEE 802.3u,IEEE 802.3an,IEEE 802.3az,IEEE 802.3ab Ethernet LAN data rates 10,1000,100 Mbit/s Full duplex Yes Ethernet LAN Yes Maximum data transfer rate 20000 Mbit/s VLAN tagging Yes Jumbo frames 15000 Auto MDIX IEEE No Auto-negotiation Yes
Design
Product colour Black,Stainless steel LED indicators Activity,Speed Internal Yes Chipset Intel - X540
Cerinţe de sistem
Windows operating systems supported Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista Home Premium x64 Linux operating systems supported Yes Server operating systems supported Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019
Conditii de mediu
Operating temperature (T-T) 5 - 50 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 20 - 80 %
Sustenabilitate
Sustainability certificates CE,RoHS Sustainability compliance Yes
Greutate şi dimensiuni
Width 20 mm Height 120 mm Depth 163 mm Weight 160 g
Datele de ambalare
Package weight 242 g Package width 208 mm Package depth 147 mm Package height 40 mm Low-profile bracket Yes
Conţinutul de ambalaje
Manual Yes
Date logistice
Harmonized System (HS) code 85176990 Master (outer) case height 308 mm Master (outer) case width 420 mm Master (outer) case length 430 mm Products per master (outer) case 40 pc(s)
