Descriere
Scanare |
Sensor type | CMOS |
Scanner type | 1D/2D |
Type | Fixed bar code reader |
2D (matrix & stacked) barcodes supported | Aztec Code,Data Matrix,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code |
Linear (1D) barcodes supported | Codabar,Code 11,Code 128,Code 39,Code 93,EAN 128,EAN-13,EAN-8,ITF-14,Industrial 2 of 5,MSI,Plessey,U.P.C. |
Pitch reading angle | -55 - 55 ° |
Yaw reading angle | 0 - 360 ° |
Tilt reading angle | -55 - 55 ° |
Conexiune
Standard interfaces RS-232 Connectivity technology Wired
Performanță
Product colour Black LED indicators Yes International Protection (IP) code IP54 Certification FCC B, CE EMC B, IEC60825, IEC62471, KC Buzzer Yes
Managementul energiei
Input voltage 5 V Power source type USB Power consumption 276.8 mA
Greutate şi dimensiuni
Weight 75 g Width 41.5 mm Depth 49.5 mm Height 24.3 mm
Conditii de mediu
Operating temperature (T-T) -20 - 60 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 5 - 95 %
Detalii tehnice
Sustainability certificates RoHS
Date logistice
Harmonized System (HS) code 84716070
