Descriere
Conexiune |
Host interface | USB 2.0 Type-B |
Ports quantity | 4 |
RS-232 ports | 4 |
Hub interfaces | Serial |
Caracteristici
Product colour Black Plug and Play Yes LED indicators Power Housing material Steel Surge protection Yes
Managementul energiei
Power plug type Type N Output voltage 12 V Output current 1 A
Cerinţe de sistem
Windows operating systems supported Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 Linux operating systems supported Yes Server operating systems supported Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019 Mac operating systems supported Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.9 Mavericks,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Mac OS X 13.0 Ventura
Greutate şi dimensiuni
Weight 382 g Depth 128 mm Width 116 mm Height 25 mm
Datele de ambalare
Package width 165 mm Package weight 598 g Package height 55 mm Package depth 240 mm
Conţinutul de ambalaje
Manual Yes Cables included USB DIN rail kit included Yes
Conditii de mediu
Operating temperature (T-T) 0 - 55 °C Storage temperature (T-T) -20 - 85 °C Operating relative humidity (H-H) 5 - 95 %
Performanță
Baud rate 921.6 Kbit/s Data bits 7,8 Stop bits 1,2 Parity bit Even,Mark,N,Odd,Space
Sustenabilitate
Sustainability certificates CE,RoHS Sustainability compliance Yes
Date logistice
Harmonized System (HS) code 84719000 Products per master (outer) case 15 pc(s) Master (outer) case width 410 mm Master (outer) case length 420 mm Master (outer) case height 280 mm
Alte caracteristici
Chipset FTDI - FT4232H
