Descriere
Conexiune |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
HDMI version | 2.0 |
USB Power Delivery | Yes |
USB Power Delivery up to | 100 W |
USB Power Delivery revision | 3.0 |
Connectivity technology | Wired |
Microphone in | No |
USB Type-C DisplayPort Alternate Mode | Yes |
Reţea
Ethernet LAN (RJ-45) ports 1 Ethernet LAN data rates 10,100,1000 Mbit/s Ethernet LAN Yes
Performanță
Card reader integrated Yes Compatible memory cards MicroSD (TransFlash),SD Product colour Grey Number of displays supported 1 Housing material Aluminium HD type 4K Ultra HD Plug and Play Yes Country of origin Taiwan Compatibility Available USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0 Maximum digital resolution 3840 x 2160 pixels Data transfer rate 10 Gbit/s Maximum refresh rate 144 Hz Charging function Yes Colour name Space Grey Display modes Extended,Mirror,Primary display
Managementul energiei
Power source type USB Output voltage 5 V Output current 0.69 A Power consumption (typical) 3.48 W Power connector USB Type-C USB cable length 0.2 m
Software
Windows operating systems supported Yes Mac operating systems supported Yes
Conditii de mediu
Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 85 % Storage temperature (T-T) -17 - 68 °C Storage relative humidity (H-H) 0 - 85 %
Greutate şi dimensiuni
Depth 50 mm Width 138 mm Height 16 mm Weight 104 g
Datele de ambalare
Package width 193 mm Package depth 125 mm Package height 22.5 mm Package weight 164 g Quantity per pack 1 pc(s)
Conţinutul de ambalaje
Manual Yes Quick start guide Yes
Detalii tehnice
Warranty period 2 year(s) Master (outer) case GTIN (EAN/UPC) 24712795086267
Date logistice
Master (outer) case length 445 mm Master (outer) case width 226 mm Master (outer) case height 190 mm Products per master (outer) case 18 pc(s) Master (outer) case gross weight 4060 g Products per shipping (inner) case 6 pc(s) Shipping (inner) case net weight 1140 g Shipping (inner) case length 212 mm Shipping (inner) case width 165 mm Shipping (inner) case height 137 mm Export Control Classification Number (ECCN) EAR99
Alte caracteristici
Special features Built-in advanced USB-C® E-Mark integrates USB4™, Thunderbolt™ 3 and Thunderbolt™ 4 compatibility, Features a 4K HDMI™ output, supporting video resolutions up to 3840 x 2160 at 60 Hz
