| Network |
| Maximum data transfer rate | 633 Mbit/s |
| Modulation | 16-QAM,64-QAM,256-QAM,CCK,COFDM,DBPSK,DQPSK,OFDM |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1x |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi | Y |
| WLAN data transfer rates supported | 11.54.150.200.433 Mbit/s |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Security algorithms | 64-bit WEP,128-bit WEP,WPA-PSK,WPA2-PSK |
| Frequency range | 2.4 - 5 GHz |
| Technical details |
| Vendor | TP-LINK |
| Packaging content |
| Quick installation guide | Y |
| Ports & interfaces |
| Connectivity technology | Wired |
| Interface | WLAN |
| Host interface | USB |
| USB version | 2.0 |
| Weight & dimensions |
| Height | 18.6 mm |
| Width | 15 mm |
| Depth | 7.1 mm |
| Design |
| Receiver sensitivity | 5GHz: 11a 6Mbps: -90dBm 11a 54Mbps: -73dBm 11n HT20 MCS0: -89dBm 11n HT20 MCS7: -70dBm 11n HT40 MCS0: -86dBm 11n HT40 MCS7: -67dBm 11ac VHT80 MCS0: -82dBm 11ac VHT80 MCS9: -56dBm 2.4GHz: 11b 1Mbps: -96dBm 11b 11Mbps: -88dBm 11g 6Mbps: -89dBm 11g 54Mbps: -74dBm 11n HT20 MCS0: -89dBm 11n HT20 MCS7: -72dBm 11n HT40 MCS0: -86dBm 11n HT40 MCS7: -66dBm |
| Product colour | Black |
| Internal | N |
| Certification | CE, FCC |
| Antenna | Y |
| Antenna design | Internal |
| Power |
| USB powered | Y |
| Sustainability |
| Sustainability certificates | RoHS |
| Operational conditions |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| System requirements |
| Windows operating systems supported | Windows 10,Windows 7,Windows 8,Windows 8.1,Windows XP |
| Mac operating systems supported | macOS |
| Linux operating systems supported | Y |
