Design
Product colour	Black
Type	Three-phase
Rack capacity	0U
PDU types	Metered,Metered-by-outlet,Switched
Mounting	Vertical
On/off switch	Yes
Form factor	Rackmount
Display	LCD
Regulatory Approvals	CE, CSA C22.2 No 62368-1, EN 62368-1, FCC part 15 subpart B, UKCA, UL 62368-1

Conexiune

AC outlets quantity 48 AC outlet(s) AC outlet types C13 coupler,C15 coupler,C19 coupler,C21 coupler Power plug IEC 60309 Ethernet LAN (RJ-45) ports 2 USB ports quantity 1

Caracteristici

Cable length 1.8 m LED indicators Activity,Network,Power Daisy chain Yes Reset button Yes Security algorithms 128-bit AES,192-bit AES,256-bit AES,DES,MD5,SNMP,SNMPv2,SNMPv3 Compatible products Compatible with most NetShelter SX enclosures and third-party racks Colour-coded outlets Yes Surge protection Yes Password protection Yes

Caracteristicile managementului

Monitoring Current,Humidity,Power,Temperature,Voltage Firmware upgradeable Yes Firmware upgradeable via Network,USB Outlet control Lock-out,Recycle,Turn off,Turn on

Managementul energiei

AC input frequency 50 - 60 Hz Nominal input voltage 400 V Nominal output voltage 230 V Maximum current 16 A Load capacity 11500 VA Maximum total current draw per phase 16 A Maximum power 11500 W Output voltage 230 V Power protection features Overload Number of phases 3

Greutate ÅŸi dimensiuni

Weight 7700 g Width 56 mm Height 1490 mm Depth 75 mm

Datele de ambalare

Package weight 9700 g Package width 208 mm Package depth 116 mm Package height 1720 mm

Conditii de mediu

Operating temperature (T-T) -5 - 60 °C Operating relative humidity (H-H) 5 - 95 % Operating altitude 0 - 3048 m Storage temperature (T-T) -25 - 65 °C Storage relative humidity (H-H) 5 - 95 % Non-operating altitude 0 - 15240 m Operating temperature (T-T) 23 - 140 °F

Detalii tehnice

Sustainability certificates RoHS
