Caracteristici
Input frequency	40 - 70 Hz
Output power capacity	6 kVA
Output power	6000 W
Audible alarm(s)	Yes
Surge energy rating	480 J
Efficiency	94.4 %
Surge protection	Yes
Input operation voltage (min)	100 V
Input operation voltage (max)	275 V
Output operation voltage (max)	240 V
Output operation voltage (min)	220 V
UPS topology	Double-conversion (Online)
Noise level	55 dB
Waveform	Sine
Number of output phases	1
Emergency Power Off (EPO)	Yes
Auto-restart	Yes
Crest factor	3:1
Output frequency regulation	50/60 Hz

Conexiune

AC outlets quantity 10 AC outlet(s) AC outlet types C13 coupler,C19 coupler Power plug Terminal USB port Yes Number of output IEC jumpers 2 Serial interface Yes SmartSlot Yes

Baterie

Battery technology Sealed Lead Acid (VRLA) Hot-swap battery Yes Battery recharge time 1.5 h Automatic battery test Yes Typical backup time at half load 8.7 min Battery life (max) 5 year(s) Cold start Yes Battery capacity 902 VAh Typical backup time at full load 2.5 min

Design

Certification REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE Product colour Black LED indicators Status Form factor Rackmount Rack capacity 4U International Protection (IP) code IP20 Display type LCD

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -15 - 45 °C Storage relative humidity (H-H) 0 - 95 % Operating altitude 0 - 3000 m Non-operating altitude 0 - 15000 m

Detalii tehnice

Sustainability certificates RoHS,ENERGY STAR

Greutate şi dimensiuni

Package width 610 mm Package height 370 mm Package depth 960 mm Weight 60000 g Width 432 mm Height 174 mm Depth 719 mm Package weight 67000 g

Datele de ambalare

Rack mount kit Yes Cables included USB cable Warranty card Yes Quick installation guide Yes Software CD Yes Bracket Yes Temperature sensor Yes

Date logistice

Products per pallet 6 pc(s) Harmonized System (HS) code 85078000
