Caracteristici
Surge protection	Yes
Surge energy rating	340 J
UPS topology	Double-conversion (Online)
Noise level	55 dB
Audible alarm(s)	Yes
Output power capacity	3 kVA
Input frequency	40/70 Hz
Output power	2700 W
Input operation voltage (max)	275 V
Input operation voltage (min)	100 V
Output operation voltage (max)	240 V
Output operation voltage (min)	220 V
Efficiency	92.4 %
Waveform	Sine
Emergency Power Off (EPO)	Yes
Auto-restart	Yes
Output frequency regulation	50/60 Hz
Web-based management	Yes

Conexiune

AC outlets quantity 8 AC outlet(s) AC outlet types C13 coupler,C19 coupler Power plug C20 coupler USB port Yes Serial interface Yes Serial interface type RJ-45 SmartSlot Yes

Baterie

Battery technology Sealed Lead Acid (VRLA) Hot-swap battery Yes Battery capacity 505 VAh Battery recharge time 3 h Typical backup time at half load 11.8 min Battery life (max) 5 year(s) Automatic battery test Yes Typical backup time at full load 4 min Cold start Yes

Design

Product colour Black Form factor Tower Certification CE, CE Mark, CSA C22.2 No.107.3-05, EAC, EN/IEC 62040-1, EN/IEC 62040-2, FCC Part 15 Class A, RCM, UL 1778, VDE, REACH LED indicators Yes Cable length 2.44 m International Protection (IP) code IP20 Display type LCD

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -15 - 45 °C Storage relative humidity (H-H) 0 - 95 % Operating altitude 0 - 3000 m Non-operating altitude 0 - 15000 m

Detalii tehnice

Sustainability certificates RoHS,ENERGY STAR

Greutate ÅŸi dimensiuni

Weight 31300 g Width 85 mm Depth 635 mm Height 432 mm Package weight 36740 g Package width 599 mm Package depth 871 mm Package height 246 mm

Datele de ambalare

Cables included RS-232,USB cable Quick installation guide Yes Software CD Yes

Date logistice

Products per pallet 6 pc(s) Harmonized System (HS) code 85078000
