Descriere
Caracteristici |
Surge protection | Yes |
Surge energy rating | 340 J |
UPS topology | Double-conversion (Online) |
Noise level | 55 dB |
Audible alarm(s) | Yes |
Output power capacity | 3 kVA |
Input frequency | 40/70 Hz |
Output power | 2700 W |
Input operation voltage (max) | 275 V |
Input operation voltage (min) | 100 V |
Output operation voltage (max) | 240 V |
Output operation voltage (min) | 220 V |
Efficiency | 93.5 % |
Waveform | Sine |
Output frequency | 50/60 Hz |
Emergency Power Off (EPO) | Yes |
Crest factor | 3:1 |
Auto-restart | Yes |
Output frequency regulation | 50/60 Hz |
Web-based management | Yes |
Conexiune
AC outlets quantity 8 AC outlet(s) AC outlet types C13 coupler,C19 coupler Power plug C20 coupler USB port Yes Serial interface Yes Serial interface type RJ-45 SmartSlot Yes Number of output IEC jumpers 2
Baterie
Battery technology Sealed Lead Acid (VRLA) Hot-swap battery Yes Battery capacity 505 VAh Number of batteries supported 1 Battery recharge time 3 h Typical backup time at half load 11.8 min Battery life (max) 5 year(s) Automatic battery test Yes Typical backup time at full load 4 min Cold start Yes
Design
Product colour Black Form factor Rackmount/Tower Rack capacity 2U Certification CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH LED indicators Yes Cable length 2.44 m International Protection (IP) code IP20 Display type LCD
Conditii de mediu
Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -15 - 45 °C Storage relative humidity (H-H) 0 - 95 % Operating altitude 0 - 3000 m Non-operating altitude 0 - 15000 m
Detalii tehnice
Sustainability certificates RoHS,ENERGY STAR
Greutate şi dimensiuni
Weight 31300 g Width 432 mm Depth 635 mm Height 85 mm Package weight 39920 g Package width 599 mm Package depth 871 mm Package height 246 mm
Datele de ambalare
Cables included USB cable Rack mount kit Yes Quick installation guide Yes Software CD Yes Warranty card Yes Bracket Yes
Date logistice
Products per pallet 6 pc(s) Harmonized System (HS) code 85078000
Alte caracteristici
Nominal input voltage 230 V Nominal output voltage 230 V
