Descriere
Caracteristici |
| Input frequency | 50/60 Hz |
| Output power capacity | 0.75 kVA |
| Output power | 500 W |
| Output frequency | 50/60 Hz |
| Audible alarm(s) | Yes |
| Surge energy rating | 459 J |
| Surge protection | Yes |
| Response time | 2 ms |
| Web-based management | Yes |
| Input operation voltage (min) | 151 V |
| Input operation voltage (max) | 302 V |
| Output operation voltage (max) | 240 V |
| Output operation voltage (min) | 220 V |
| UPS topology | Line-Interactive |
| Noise level | 46 dB |
| Waveform | Sine |
| Emergency Power Off (EPO) | O |
| Output voltage regulation | 5 % |
| Auto-restart | Yes |
| Audible alarm modes | Battery replacement |
| Output frequency regulation | +/- 3 Hz |
Conexiune
Ethernet LAN (RJ-45) ports 1 AC outlets quantity 4 AC outlet(s) AC outlet types C13 coupler,C14 coupler Power plug C14 coupler USB 2.0 ports quantity 1
Baterie
Battery technology Sealed Lead Acid (VRLA) Hot-swap battery Yes Battery capacity 168 Ah Battery recharge time 3 h Automatic battery test Yes Cold start Yes
Design
Certification CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE Product colour Black LED indicators Yes Form factor Rackmount Rack capacity 2U Display type LCD
Conditii de mediu
Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -15 - 45 °C Storage relative humidity (H-H) 0 - 95 % Operating altitude 0 - 3000 m Non-operating altitude 0 - 15000 m
Detalii tehnice
Sustainability certificates Green Premium,RoHS
Greutate şi dimensiuni
Package width 546 mm Package height 241 mm Package depth 584 mm Weight 17240 g Width 432 mm Height 89 mm Depth 406 mm Package weight 21180 g
Datele de ambalare
Rack mount kit Yes Cables included Input power cable,USB cable Quick installation guide Yes Resource CD Yes
Date logistice
Products per pallet 16 pc(s) Harmonized System (HS) code 85078000
Alte caracteristici
Output voltage 230 V
