Caracteristicile managementului
Switch type	Managed
ARP inspection	Yes

Conexiune

Console port RJ-45 Basic switching RJ-45 Ethernet ports quantity 8 Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000) Gigabit Ethernet (copper) ports quantity 6 Installed SFP+ modules quantity 2 2.5G Ethernet (copper) ports quantity 2

Reţea

Networking standards IEEE 802.1Q,IEEE 802.1x,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt 10G support Yes VLAN support Yes Virtual LAN features Private VLAN

Transmisie de date

Switching capacity 62 Gbit/s MAC address table 16000 entries Throughput 46.12 Mpps Jumbo frames support Yes Jumbo frames 10240

Securitate

Security algorithms HTTPS Access Control List (ACL) Yes DHCP features DHCP snooping Password protection Yes

Protocoale

Supported network protocols IPv4, IPv6, HTTP, HTTPS, SMTP, Bonjour, UPnP®, SNMP v1/v2c/v3, DNS, NTP, RTSP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH, RADIUS, TACACS+, Syslog, IEEE 802.1X, 802.1Q (VLAN), LLDP, LLDP-Med, STP, MSTP, RSTP, LACP, RRPP

Design

Product colour Black Housing material Aluminium Certification EMC EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, IEC 62236-4, FCC part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, VCCI Class A, RCM AS/NZS CISPR 32 Class A Safety IEC/EN/UL 62368-1 ed. 3 Environment IEC 60068-2-6, IEC 60068-2-27, NEMA TS 2 (2.2.7-2.2.9), 60068-2-31 (Free fall - Procedure 1), IEC/EN 60529 IP30

Managementul energiei

Power source DC/PoE

Curent pe cablu net (PoE)

Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 480 W Power over Ethernet (PoE) power per port 90 W Power over Ethernet (PoE) ports quantity 8

Conditii de mediu

Operating temperature (T-T) -40 - 60 °C Storage temperature (T-T) -40 - 85 °C Operating relative humidity (H-H) 5 - 95 % Storage relative humidity (H-H) 5 - 95 %

Greutate şi dimensiuni

Weight 892 g Width 62 mm Depth 130 mm Height 168 mm
