Performanță
Connectivity technology	Wired
Type	IP security camera
Certification	EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, EN 50121-4, EN 50121-3-2, IEC 62236-4, ECE R10 rev.05 (E approval), EN 50498, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, EN 45545, UN ECE R118, NFPA 130, IEC 62471, IEC/EN 61373 Category 1 Class B, IEC/EN 60529 IP66, IEC/EN 60529 IP67, NEMA 250 Type 4X, IEC/EN 62262 IK10, IEC 60721-3-5 Class 5M3 (vibration and shock), EN 50155 Class OT2/ST2 (2017 Class TX), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-64, IEC 60068-2-78, NIST SP500-267
PTZ control	Yes
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
PTZ modes	Digital PTZ
Preset points	Yes

Design

Product colour Black,White Form factor Dome Mounting type Ceiling International Protection (IP) code IP66, IP67 Housing material Aluminium IK code IK10 Fog proof Yes

Aparat de fotografiat

Minimum illumination 0.01 lx Tilt angle range 15 - 90 ° Pan range -30 - 30 ° Angle of rotation 350 ° Camera tilt control Yes Camera pan control Yes Lens viewing angle, vertical 62 ° Lens viewing angle, horizontal 110 °

Senzor de imagine

Sensor type CMOS Optical sensor size 1/2.9 " Progressive scan Yes Number of sensors 1

Sistem de lentile

Fixed focal length 2.8 mm Number of lenses 1

Vizibilitate nocturnă

Night vision Yes LED type IR Night vision distance 15 m Infra-red wavelength 940 nm

Video

Maximum resolution 1920 x 1080 pixels Frame rate 45 fps Video compression formats AVC,H.264,H.265,HEVC,M-JPEG,MPEG4 Supported graphics resolutions 160 x 120,160 x 90,1280 x 960,1920 x 1080 (HD 1080) Image quality adjustment Brightness,Contrast,Sharpness Video streaming Yes Privacy masking Yes Total megapixels 2 MP Text caption overlay Yes Bit rate control Variable Bit Rate (VBR) Image stabilizer Yes

Audio

Audio formats supported AAC-LC,G.711,LPCM,PCM Audio system 1-way Sample rate 48 kHz

Reţea

Ethernet LAN Yes Supported network protocols IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT Networking standards IEEE 802.1x,IEEE 802.3af,IEEE 802.3at Ethernet interface type Fast Ethernet Quality of Service (QoS) support Yes Streaming method Multicast Number of users 8 user(s)

Medii de stocare

Card reader integrated Yes Flash memory 512 MB

Conexiune

Microphone in Yes

Securitate

IP address filtering Yes HTTPS encryption Yes Video motion detection Yes Password protection Yes Active tampering alarm Yes

Managementul energiei

Power source type PoE Power consumption (typical) 6.6 W Power consumption (max) 11.8 W

Conditii de mediu

Operating temperature (T-T) -40 - 55 °C Operating relative humidity (H-H) 10 - 95 % Storage temperature (T-T) -40 - 65 °C

Greutate şi dimensiuni

Weight 410 g Height 49.4 mm Width 110 mm Depth 110 mm

Conţinutul de ambalaje

Number of cameras 1 Manual Yes

Date logistice

Harmonized System (HS) code 85258900
