Performanță
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Certification	CSA, UL/cUL, UKCA, CE, KC
Languages support	CHI (SIMPL),CHI (TR),CZE,DEU,DUT,ENG,ESP,FIN,FRE,ITA,JPN,KOR,POL,POR,RUS,SWE,THA,TUR,VIE
Number of languages	19
Thermal module	Yes
Processor model	ARTPEC-8
Built-in processor	Yes
Thermal sensitivity (NETD)	40 mK

Design

Product colour White Housing material Aluminium,Polycarbonate (PC) International Protection (IP) code IP66, IP67 Mounting type Wall Form factor Bullet IK code IK10

Aparat de fotografiat

Lens viewing angle, horizontal 28 ° Camera pixel size 17 µm

Senzor de imagine

Sensor type Microbolometer Sensor type (thermal module) Noise equivalent temperature difference (NETD)

Sistem de lentile

Maximum aperture number 1 Lens diameter 13 mm

Vizibilitate nocturnă

Night vision No

Video

Video compression formats H.264,H.265,M-JPEG Maximum resolution 384 x 288 pixels Frame rate 30 fps Privacy masking Yes Video streaming Yes Video recording Yes Gain control type Auto

Audio

Audio system 1-way Audio input channels 1 channels Audio output channels 1 channels

Reţea

Networking standards IEEE 802.1x,IEEE 802.3af,IEEE 802.3at Supported network protocols IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) Ethernet interface type Gigabit Ethernet Ethernet LAN Yes Wi-Fi No Bluetooth No Quality of Service (QoS) support Yes

Medii de stocare

Card reader integrated Yes Flash memory 8192 MB Compatible memory cards MicroSD (TransFlash),MicroSDHC,MicroSDXC Internal memory 2048 MB Built-in HDD No

Conexiune

Ethernet LAN (RJ-45) ports 1 DC-in jack Yes Headphone outputs 1 Terminal block port Yes

Securitate

Video motion detection Yes Temperature sensor Yes IP address filtering Yes Password protection Yes Active tampering alarm Yes Pixel counter Yes Digest authentication Yes Network access storage (NAS) Yes Mirror Yes Fire detection Yes Temperature measurement accuracy 5 °C Temperature measurement range -40 - 350 °C

Managementul energiei

Power source type DC,PoE Power consumption (max) 12.95 W Power consumption (typical) 4.1 W Power consumption (Power over Ethernet (PoE)) 4.3 W DC output voltage 10,12,15,16,24,28

Conditii de mediu

Operating temperature (T-T) -40 - 60 °C Operating relative humidity (H-H) 10 - 100 % Storage temperature (T-T) -40 - 65 °C Storage relative humidity (H-H) 5 - 95 %

Greutate ÅŸi dimensiuni

Weight 1400 g Diameter 132 mm Length 272 mm

Conţinutul de ambalaje

Manual Yes Number of cameras 1
