Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2
MIB support	Yes
Configuring Location Settings (CLI)	Yes

Conexiune

SFP module slots quantity 4 Console port RJ-45/USB Type-C Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 28

Reţea

Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3az VLAN support Yes Number of VLANs 255 Link aggregation Yes 10G support No Spanning tree protocol Yes Broadcast storm control Yes Port mirroring Yes Head-of-line (HOL) blocking Yes

Transmisie de date

Jumbo frames support Yes MAC address table 8000 entries Switching capacity 56 Gbit/s Forwarding rate 41.66 Mpps Jumbo frames 9000 Packet buffer memory 1.5 MB Number of queues 8

Securitate

Security algorithms 802.1x RADIUS Loop protection Yes Access Control List (ACL) rules 512 Queue scheduling algorithms Weighted Round Robin (WRR) DoS attack prevention Yes

Specificații (mod transmitere) multicast

Multicast support Yes

Protocoale

GARP VLAN Registration Protocol (GVRP) Yes

Design

Product colour White Rack mounting Yes LED indicators Yes Certification UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A Country of origin China Reset button Yes Form factor 1U

Performanță

Mean time between failures (MTBF) 698220 h Firmware upgradeable Yes Internal memory 1000 MB Flash memory 512 MB Memory type DDR4-SDRAM Built-in processor Yes Processor frequency 1.4 MHz

Managementul energiei

AC input frequency 50/60 Hz AC input voltage 100 - 240 V Power consumption (typical) 10.65 W Power plug type Type C Power source AC Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 195 W

Conditii de mediu

Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -25 - 70 °C Storage relative humidity (H-H) 10 - 90 %

Greutate ÅŸi dimensiuni

Width 298.704 mm Depth 444.5 mm Height 43.942 mm Weight 3530 g

Datele de ambalare

Package weight 5823.13 g Package width 430.022 mm Package depth 575.056 mm Package height 105.918 mm
