Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2
ARP inspection	Yes
System event log	Yes

Conexiune

SFP module slots quantity 2 Console port RJ-45 Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100) Basic switching RJ-45 Ethernet ports quantity 10 Compatible memory cards SD

Reţea

Networking standards IEEE 802.1x,IEEE 802.3 VLAN support Yes Number of VLANs 256 Virtual LAN features VLAN Identifier ( VLAN ID) 10G support No Spanning tree protocol Yes Broadcast storm control Yes Rate limiting Yes

Transmisie de date

MAC address table 8000 entries Number of queues 8

Securitate

Security algorithms SNMP,SNMPv3,SSH MAC address filtering Yes Access Control List (ACL) Yes DHCP features DHCP server,DHCP snooping IGMP snooping Yes BPDU filtering/protection Yes Authentication Guest VLAN,MAC-based authentication Access Control List (ACL) rules 1500 IGMP entries 1000

Specificații (mod transmitere) multicast

Multicast support Yes

Design

Product colour Black Certification UL/CSA 60950-1,CB to IEC 60950-1, UL/CSA 62368-1, CB to IEC 62368-1, UL/CSA 61010-2-201, CB IEC/EN 61010-2-201, UL121201(l, Div 2, A-D), SA 213 (l, Div 2, A-D), UL/CSA 60079-0, -15 (l, 2, Gc/IIC), IEC 60079-0, -15 IECEx (l, 2, Gc/IIC), EN 60079-0, -15 ATEX (l, 2, Gc/IIC), EN 61000-6-2 EN 61000-6-4 EN 61000-6-1 EN 61326-1 IEEE 1613 EN/IEC 61850-3 EN50121-4 ODVA International Protection (IP) code IP30 Electromagnetic compatibility FCC 47 CFR 15 B A, EN 55032/CISPR 32 A, VCCI A, AS/NZS CISPR 32 A, CISPR 11 A, ICES 003 A, CNS 13438 A, KN 32 A, EN 300 386 DIN rail mounting Yes

Performanță

Mean time between failures (MTBF) 613125 h Internal memory 2048 MB Flash memory 1500 MB Memory type DRAM Dying Gasp Yes

Managementul energiei

Power consumption (typical) 35 W Input current 5.5 A DC input voltage 9.6 - 60 V Redundant power supply (RPS) support Yes

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 8 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 240 W

Conditii de mediu

Operating temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 5 - 95 % Storage temperature (T-T) -40 - 85 °C

Greutate şi dimensiuni

Width 91.44 mm Depth 134.62 mm Height 152.4 mm Weight 1700.971 g

Date logistice

Harmonized System (HS) code 85176990
