Caracteristicile managementului
Quality of Service (QoS) support	Yes
Switch type	Managed
Switch layer	L2
MIB support	802.1X MIB, CISCO-DHCP-SNOOPING-MIB, CISCO-UDLDP-MIB, CISCO-ENVMON-MIB, CISCO-PRIVATE-VLAN-MIB, CISCO-PAE-MIB, Cisco-Port-QoS-MIB, CISCO-ERR-DISABLE-MIB, CISCO- PROCESS-MIB, LLDP-MIB, CiscoMACNotification-MIB, CISCO-CONFIG-COPY-MIB, LLDP-MED-MIB, Bridge-MIB, CISCO-CAR-MIB, CISCO-LAG-MIB, CISCO-SYSLOG-MIB, CISCO-FTP-CLIENT-MIB, CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB, CISCO-VLAN-MEMBERSHIP-MIB, Cisco-REP-MIB, CISCO-PORT-STORM-CONTROL-MIB, CISCO-CDP-MIB, CISCO-IP-STAT-MIB, CISCO-LICENSE-MGMT-MIB, CISCO-STP-EXTN-MIB, CISCO-VTP-MIB, IEEE8023-LAG-MIB, SMON-MIB, CISCO-ACCESS-ENVMON-MIB, CISCO-CALLHOME-MIB, CISCO-CONFIG-MAN-MIB, CISCO-FLASH-MIB, CISCO-ENTITY-SENSOR-MIB, IP-MIB, CISCO-PAGP-MIB
ARP inspection	Yes
System event log	Yes

Conexiune

USB 2.0 ports quantity 2 Gigabit Ethernet (copper) ports quantity 8 SFP module slots quantity 2 Console port RJ-45 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 8 Power connector DC-in jack Compatible memory cards SD

Reţea

Networking standards IEEE 1588,IEEE 802.11ac,IEEE 802.11n,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ah,IEEE 802.3u,IEEE 802.3x Number of VLANs 256 Link aggregation Yes 10G support No Spanning tree protocol Yes Broadcast storm control Yes

Transmisie de date

Jumbo frames support Yes MAC address table 8000 entries Jumbo frames 8996 Number of queues 8

Securitate

Security algorithms 802.1x RADIUS,SNMPv3,SSH MAC address filtering Yes Access Control List (ACL) Yes DHCP features DHCP server IGMP snooping Yes BPDU filtering/protection Yes Authentication Guest VLAN,MAC-based authentication Authentication type IEEE 802.1x,RADIUS,TACACS+ IGMP entries 1000 Access Control List (ACL) ingress 3000

Specificații (mod transmitere) multicast

Multicast support Yes

Protocoale

Management protocols IEEE 802.1, 802.3 standard, NTP, UDLD, CDP, LLDP, unicast MAC filter, PAgP, LACP VTPv2, VTPv3, EtherChannel, voice VLAN, PVST+, MSTP, and RSTP Switching protocols IGMPv1, v2, v3 snooping, IGMP filtering, IGMP querier

Design

Product colour Black Rack mounting Yes LED indicators Yes Certification UL, BSMI CNS 13438 Class A, CISPR 24, cUL, EN55022, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, NOM, VCCI Class A ITE, IEC 60950, EN55 International Protection (IP) code IP20 DIN rail mounting Yes

Performanță

Mean time between failures (MTBF) 633420 h Internal memory 2000 MB Flash memory 1500 MB

Managementul energiei

Power consumption (typical) 23 W Input current 3.8 A DC input voltage 9.6 - 60 V Redundant power supply (RPS) support Yes Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Operating temperature (T-T) -40 - 75 °C Operating relative humidity (H-H) 5 - 95 % Storage temperature (T-T) -40 - 85 °C Operating altitude 0 - 4572 m Storage relative humidity (H-H) 5 - 95 %

Greutate şi dimensiuni

Width 91 mm Depth 135 mm Height 152 mm Weight 1700 g

Date logistice

Harmonized System (HS) code 85176990
