Scanare |
Scanner type | 1D/2D |
Type | Handheld bar code reader |
2D (matrix & stacked) barcodes supported | Aztec Code,Composite Codes,Data Matrix,Han Xin,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code,TLC-39 |
Linear (1D) barcodes supported | Codabar,Code 11,Code 128,Code 39,Code 93,GS1-128 (UCC/EAN-128),MSI,Plessey,U.P.C. |
Pitch reading angle | -65 - 65 ° |
Sensor type | Laser |
Yaw reading angle | -45 - 45 ° |
Tilt reading angle | -65 - 65 ° |
Wavelength | 655 nm |
Optical sensor resolution | 1280 pixels |
Conexiune
Standard interfaces RS-232,USB,Keyboard wedge Connectivity technology Wired Ethernet LAN Yes
Performanță
Product colour Black,Green International Protection (IP) code IP67 LED indicators Yes Protection features Dust resistant,Shock resistant,Water resistant Programming function Yes
Managementul energiei
Power source type Battery Battery technology Lithium-Ion (Li-Ion) Battery capacity 3100 mAh Number of reads per charge 70000
Greutate şi dimensiuni
Width 132 mm Depth 76 mm Height 185 mm Weight 334 g
Conditii de mediu
Operating temperature (T-T) -30 - 50 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 5 - 95 %
Detalii tehnice
Sustainability certificates RoHS
Date logistice
Harmonized System (HS) code 84716070
