DS50U3 I3-1315U 90W EXT./LAN HDMI DISPLAY-PORT COM-PORT

DS50U3 I3-1315U 90W EXT./LAN HDMI DISPLAY-PORT COM-PORT
DS50U3 I3-1315U 90W EXT./LAN HDMI DISPLAY-PORT COM-PORT

Shuttle XPC slim Barebone DS50U3
Intel i3-1315U
2x LAN (1x 2.5Gbit
1x 1Gbit)
1xCOM
1xHDMI
1xDP
1x VGA
fanless
24/7 permanent operation;Chassis type: 1.3L sized PC
Product type: Mini PC barebone;BIOS type: UEFI AMI;Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Maximum internal memory: 64 GB;Supported storage drive types: HDD & SSD
Storage drive interface: PCI Express
Serial ATA III;Ethernet LAN (RJ-45) ports: 2;Cooling type: Passive;Power supply: 90 W

Branduri de top din categoria Mini PC Barebone :

Descriere


Descriere

Procesor

Processor model i3-1315U
Processor cores 6
Processor manufacturer Intel
Processor family Intel® Core™ i3
Processor threads 8
Built-in processor Yes
Processor boost frequency 4.5 GHz
Processor cache 10 MB
Processor generation Intel Core i3-13xxx
ECC supported by processor No
Efficient cores 4
Efficient-core boost frequency 3.3 GHz
Performance cores 2
Performance-core boost frequency 4.5 GHz

Memorie

Maximum internal memory 64 GB Supported memory types DDR5-SDRAM Number of memory slots 2 Memory channels Dual-channel Memory slots type SO-DIMM Supported memory clock speeds 5200 MHz Memory voltage 1.1 V

Medii de stocare

Number of storage drives supported 3 Supported storage drive types HDD & SSD Storage drive sizes supported 2.5,M.2 " Storage drive interface PCI Express,Serial ATA III NVMe Yes

Grafică

On-board graphics card Yes On-board graphics card model Intel® UHD Graphics Graphics card family Intel

Audio

Built-in speaker(s) No

Reţea

Wi-Fi No Ethernet LAN Yes LAN controller Intel I219,Intel I226-LM

Conexiune

HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 2 HDMI version 2.0b USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4 USB 2.0 ports quantity 2 DisplayPorts quantity 1 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2 DC-in jack Yes DisplayPort version 1.4 Microphone in Yes Headphone outputs 1 VGA (D-Sub) ports quantity 1 Serial ports quantity 1

Design

Product type Mini PC (<= 3L) barebone Product colour Black Chassis type 1.3L sized PC Cable lock slot Yes Cable lock slot type Kensington Housing material Steel VESA mounting Yes On/off switch Yes Cooling type Passive LED indicators HDD,Power Panel mounting interface 75 x 75,100 x 100 mm

Performanță

Number of processors supported 1 Trusted Platform Module (TPM) Yes BIOS type UEFI AMI Trusted Platform Module (TPM) version 2.0 Audio chip RealTek ALC888S

Software

Operating system installed No Windows operating systems supported Windows 10,Windows 11 Linux operating systems supported Yes

Date logistice

Harmonized System (HS) code 84733080

Sustenabilitate

Sustainability certificates BSMI,CB,CE,ENERGY STAR,ErP,Federal Communications Commission (FCC),RCM,RoHS,VCCI,cTUVus Sustainability compliance Yes

Managementul energiei

Power supply 90 W AC adapter output voltage 19 V AC input voltage 100 - 240 V AC input frequency 50/60 Hz Power supply type External AC adapter Number of power supply units 1 AC adapter output current 1.6 A

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 90 %

Greutate şi dimensiuni

Width 200 mm Depth 165 mm Height 39.5 mm Weight 1600 g Package weight 2300 g

Conţinutul de ambalaje

Power cord included Yes AC adapter included Yes Quick start guide Yes



mai mult

DS50U3 I3-1315U 90W EXT./LAN HDMI DISPLAY-PORT COM-PORT

Referintă: 281865
SKU: DS50U3
Compară:
2,80090
TVA inclus 2,353.70RON
464.80€
În stoc (8buc)
Livrare până în 11 iunie


Cere detalii
Te notificam imediat ce articolul va fi publicat!


Comercializat din 10/05/2024
Ridică din Alege Easybox
Transport Gratuit
în cazul produselor cu o greutate mai mare de 30kg, se pot adăuga taxe de expeditie, comunicate ulterior de catre un operator
Toate prețurile includ TVA
