afișaj
Display diagonal	15.6 "
Display resolution	1920 x 1080 pixels
Display brightness	350 cd/m²
Touchscreen	Yes
Native aspect ratio	16:9
HD type	Full HD
Panel type	LCD

Procesor

Processor model i5-1245UL Processor family Intel® Core™ i5 Processor frequency 1.6 GHz Processor cores 10 Processor cache 12 MB Processor manufacturer Intel Processor cache type Smart Cache Performance-core Max Turbo Frequency 4.4 GHz Processor base power 15 W Efficient cores 8 Performance cores 2 Maximum turbo power 28 W Efficient-core Max Turbo Frequency 2.5 GHz Performance-core boost frequency 4.4 GHz

Memorie

Internal memory 8 GB Internal memory type DDR5-SDRAM Maximum internal memory 32 GB Memory slots 2 Memory layout (slots x size) 1 x 8 GB Memory clock speed 4800 MHz Memory slots type SO-DIMM Memory form factor DIMM/SO-DIMM

Medii de stocare

Total storage capacity 128 GB Storage media SSD SSD capacity 128 GB Optical drive type No Number of SSDs installed 1 Number of storage drives installed 1 Total SSDs capacity 128 GB

Grafică

On-board graphics card model Intel Iris Xe Graphics On-board graphics card Yes Discrete graphics card model Not available On-board graphics card family Intel Iris Xe Graphics Discrete graphics card No On-board GPU manufacturer Intel

Audio

Built-in speaker(s) Yes Number of speakers 2 RMS rated power 4 W

Aparat de fotografiat

Built-in camera No

Reţea

Ethernet LAN Yes Wi-Fi Yes Wi-Fi standards 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) Bluetooth Yes Bluetooth version 5.2 Ethernet LAN data rates 10,100,1000 Mbit/s Top Wi-Fi standard Wi-Fi 6 (802.11ax)

Conexiune

Ethernet LAN (RJ-45) ports 1 USB 2.0 ports quantity 4 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4 Headphone outputs 1 DC-in jack Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1

Design

Product colour Black On/off button Yes

Performanță

Product type All-in-One PC Trusted Platform Module (TPM) Yes Trusted Platform Module (TPM) version 2.0 HDD user password Yes

Software

Operating system installed Windows 10 IoT Enterprise

Managementul energiei

AC adapter output voltage 24 V AC adapter input voltage 100 - 240 V AC adapter frequency 50 - 60 Hz AC adapter power 180 W

Greutate şi dimensiuni

Package weight 5000 g Package depth 345 mm Package width 497 mm Package height 197 mm Weight (with stand) 3100 g Width (with stand) 384.1 mm Depth (with stand) 37.2 mm Height (with stand) 147.7 mm

Conditii de mediu

Operating temperature (T-T) 0 - 35 °C Operating relative humidity (H-H) 20 - 80 % Storage temperature (T-T) -20 - 60 °C Storage relative humidity (H-H) 5 - 95 %

Certificate

Certification Canada cUL, IC; United States UL, FCC; Germany TUV; Europe CE; Australia RCM; United Kingdom UKCA; International CB; Argentina S-Mark; Brazil ANATEL; Japan VCCI, MIC; China CCC, SRRC; Mexico NOM; RoHS CoC
