Descriere
Scanare |
Sensor type | CMOS |
Scanner type | 1D/2D |
Type | Handheld bar code reader |
2D (matrix & stacked) barcodes supported | Aztec Code,Data Matrix,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code |
Linear (1D) barcodes supported | Codabar,Code 11,Code 128,Code 39,Code 93,EAN-13,EAN-8,ITF-14,ITF-6,MSI,Plessey,UPC-A,UPC-E |
Pitch reading angle | 0 - 55 ° |
Optical sensor resolution (W x H) | 1280 x 800 pixels |
Conexiune
Standard interfaces USB Connectivity technology Wired
Performanță
Product colour Black International Protection (IP) code IP42 Print contrast 30 %
Managementul energiei
Power consumption (typical) 1.53 W Input voltage 5 V Power source type USB Power consumption 306 mA
Greutate şi dimensiuni
Weight 202 g Width 68 mm Depth 61.8 mm Height 68.2 mm Base weight 324 g Base dimensions 75 x 75 x 153.5 mm
Conditii de mediu
Operating temperature (T-T) -20 - 60 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 5 - 95 %
