Descriere
Scanare |
Scanner type | 1D |
Type | Handheld bar code reader |
Linear (1D) barcodes supported | GS1 DataBar |
Pitch reading angle | -65 - 65 ° |
Sensor type | CCD |
Yaw reading angle | -65 - 65 ° |
Tilt reading angle | -45 - 45 ° |
Light levels (direct sunlight) | 0 - 130000 lx |
Read rate (max) | 400 reads/s |
Scanner resolution | 0.077 mm |
Conexiune
Standard interfaces RF Wireless Connectivity technology Wireless Wireless range 50 m Operating frequency 433 MHz
Performanță
Product colour White International Protection (IP) code IP52 LED indicators Yes Protection features Electrostatic Discharge (ESD) protection
Managementul energiei
Input voltage 4.5 - 14 V Power source type Battery Battery technology Lithium-Ion (Li-Ion) Battery capacity 2550 mAh Number of reads per charge 80000 Charging time 4 h Battery type Built-in battery Number of batteries supported 1 Battery voltage 3.6 V
Greutate şi dimensiuni
Width 166 mm Depth 68 mm Height 109 mm Weight 235 g
Datele de ambalare
Cables included USB Charging base Yes
Conditii de mediu
Operating temperature (T-T) -10 - 50 °C Storage temperature (T-T) -20 - 70 °C Operating relative humidity (H-H) 0 - 95 %
Detalii tehnice
Sustainability certificates RoHS
Date logistice
Harmonized System (HS) code 84716070
