| Network |
| Maximum data transfer rate | 10000 Mbit/s |
| Ethernet LAN | Y |
| Networking standards | IEEE 802.1p,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ad |
| Maximum operating distance | 100 m |
| LAN controller | Intel® X540 |
| Quality of Service (QoS) support | Y |
| Ethernet LAN data rates | 100.1000.10000 Mbit/s |
| Technical details |
| Vendor | Intel |
| Ports & interfaces |
| Connectivity technology | Wired |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 2 |
| Host interface | PCI Express |
| PCI version | 2.1 |
| Other features |
| Intel® Virtualization Technology (Intel® VT) | VT-c |
| Intel Virtual Machine Device Queues (VMDq) | Y |
| PCI-SIG* SR-IOV Capable | Y |
| On-chip QoS and Traffic Management | Y |
| Intel Flexible Port Partitioning | Y |
| Speed & slot width | 5.0 GT/s, x8 Lane |
| Low halogen options available | N |
| Intelligent Offloads | Y |
| iWARP (RDMA) | N |
| Intel Ethernet Power Management | N |
| Intel Data Direct I (O Technology) | Y |
| Intel Virtualization Technology for Connectivity (VT-c) | Y |
| Halogen-free | N |
| Thermal Design Power (TDP) | 13.4 W |
| Cable type | RJ45 Category 6 up to 55 m, Category 6A up to 100 m |
| Storage Over Ethernet | iSCSI, FCoE, NFS |
| Product type | Network Interface Card |
| Status | Launched |
| Launch date | Q1''12 |
| Product brief URL | http://www.intel.com/content/www/us/en/network-adapters/10-gigabit-network-adapters/ethernet-x540-t2-brief.html |
| Network interface card type | Server |
| Network interface card cable medium | Copper |
| Market segment | SRV |
| Last change | 64826822 |
| Harmonized System (HS) code | 8517620090 |
| Product family | Intel 10 Gigabit server adapter |
| Product series | Intel Converged X540 |
| Ethernet adapter ARK ID | 58954 |
| Controller type | Intel® Ethernet Controller X540 |
| Thermal power | 13.4 W |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G135872 |
| Bracket height | Low Profile and Full Height |
| Cabling type | RJ45 Category 6 up to 55 m, Category 6A up to 100 m |
| Interface type | PCIe v2.1 (5.0 GT/s) |
| Design |
| Internal | Y |
| Chipset | X540 |
| PCI Card form factor | Full-height (low-profile) |
| System requirements |
| Compatible operating systems | https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html |
| Windows operating systems supported | Y |
| Linux operating systems supported | Y |
