Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L3
Traffic classification	Yes
Configuring Location Settings (CLI)	Yes
Traffic shaping	Yes

Conexiune

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 48 Installed SFP+ modules quantity 4

Reţea

Flow control support Yes Networking standards IEEE 802.1x,IEEE 802.2,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Number of VLANs 4094 Link aggregation Yes Full duplex Yes Virtual LAN features Port-based VLAN,Private VLAN,Voice VLAN 10G support Yes Spanning tree protocol Yes Broadcast storm control Yes IP routing Yes Port mirroring Yes Policy-based routing Yes

Transmisie de date

Jumbo frames support Yes MAC address table 16000 entries Switching capacity 176 Gbit/s Forwarding rate 130.9 Mpps Latency (1 Gbps) 7.63 µs Latency (10 Gbps) 1.63 µs Latency (10-100 Mbps) 8.29 µs

Securitate

MAC address filtering Yes Access Control List (ACL) Yes DHCP features DHCP client,DHCP snooping IGMP snooping Yes SSH/SSL support Yes BPDU filtering/protection Yes Authentication MAC-based authentication Loop protection Yes

Specificații (mod transmitere) multicast

Multicast support Yes

Protocoale

Management protocols SNMP

Design

Product colour Grey Rack mounting Yes Form factor 1U Stackable Yes

Performanță

Noise level 42 dB Internal memory 16384 MB Flash memory 256 MB Memory type DDR3-SDRAM

Managementul energiei

Power consumption (max) 60 W Power source AC Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Heat dissipation 205 BTU/h Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 5 - 90 % Storage temperature (T-T) -25 - 70 °C Operating altitude 0 - 3000 m Storage relative humidity (H-H) 5 - 95 % Non-operating altitude 0 - 4000 m

Greutate ÅŸi dimensiuni

Width 441 mm Depth 323 mm Height 44 mm Weight 4800 g

Datele de ambalare

Package weight 6800 g Package width 563 mm Package depth 534 mm Package height 128 mm Cables included AC
