Descriere
Scanare |
Sensor type | LED |
Scanner type | 2D |
Type | Fixed bar code reader |
2D (matrix & stacked) barcodes supported | Aztec Code,Data Matrix,MaxiCode,QR Code |
Light levels (direct sunlight) | 0 - 86.1 lx |
Pitch reading angle | -65 - 65 ° |
Yaw reading angle | -75 - 75 ° |
Tilt reading angle | 0 - 360 ° |
Optical sensor resolution (W x H) | 1280 x 800 pixels |
Scanner resolution | 0.13 mm |
Conexiune
USB version 2.0 Standard interfaces USB Connectivity technology Wired
Performanță
Product colour Black International Protection (IP) code IP52 Certification EN62471, IEC62471 Buzzer Yes Housing material Plastic Image formats supported BMP,JPEG
Managementul energiei
Input voltage 5 V Power source type USB Power consumption 500 mA
Greutate şi dimensiuni
Weight 240 g Width 60 mm Depth 75 mm Height 150 mm
Conditii de mediu
Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 5 - 95 %
Detalii tehnice
Sustainability certificates RoHS
Date logistice
Harmonized System (HS) code 84716070
