Procesor
Processor model	i7-1255U
Processor cores	10
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor threads	12
Built-in processor	Yes
CPU configuration (max)	1
Processor cache	12 MB
Processor generation	12th gen Intel® Core™ i7
Efficient cores	8
Performance cores	2

Memorie

Maximum internal memory 64 GB Supported memory types DDR4-SDRAM Number of memory slots 2 Memory channels Dual-channel Memory slots type SO-DIMM Supported memory clock speeds 3200 MHz ECC No Memory voltage 1.2 V Non-ECC Yes

Medii de stocare

Number of storage drives supported 3 Supported storage drive types HDD & SSD Storage drive sizes supported 2.5,M.2 " Storage drive interface PCI Express,Serial ATA III Card reader integrated No NVMe Yes

Grafică

On-board graphics card Yes On-board graphics card model Intel® UHD Graphics Graphics card family Intel Maximum resolution 7680 x 4320 pixels

Audio

Built-in speaker(s) No

Reţea

Wi-Fi No Ethernet LAN Yes LAN controller Intel® I219

Conexiune

HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 HDMI version 2.0b USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4 DisplayPorts quantity 1 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2 DC-in jack Yes DisplayPort version 1.4a Microphone in Yes Headphone outputs 1 USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1

Sloturi de extensie

PCI Express slots version 3.0,4.0 Number of M.2 (M) slots 2

Design

Product type Mini PC (<= 3L) barebone Product colour Black Chassis type 0.84L sized PC Cable lock slot Yes Cable lock slot type Kensington Housing material Plastic VESA mounting Yes On/off switch Yes Cooling type Active LED indicators HDD,Power Safety CB IEC60950/62368, cTUVus (UL 62368) Panel mounting interface 75 x 75,100 x 100 mm

Performanță

Number of processors supported 1 Trusted Platform Module (TPM) Yes BIOS type AMI Motherboard chipset Intel SoC Trusted Platform Module (TPM) version 2.0

Software

Operating system installed No Windows operating systems supported Windows 10,Windows 11 Linux operating systems supported Yes

Date logistice

Harmonized System (HS) code 84733080

Sustenabilitate

Sustainability certificates BSMI,CE,ENERGY STAR,ErP,Federal Communications Commission (FCC),RoHS,UKCA Sustainability compliance Yes

Managementul energiei

Power supply 65 W AC adapter output voltage 19 V AC input voltage 100 - 240 V AC input frequency 50/60 Hz Power supply type External AC adapter Number of power supply units 1 AC adapter output current 3.42 A

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 90 %

Greutate şi dimensiuni

Width 142 mm Depth 142 mm Height 42 mm Weight 400 g Package weight 1200 g

Conţinutul de ambalaje

Drivers included Yes Power cord included Yes AC adapter included Yes Quick start guide Yes
