Descriere
Scanare |
Scanner type | 1D/2D |
Type | Handheld bar code reader |
2D (matrix & stacked) barcodes supported | Aztec Code,Data Matrix,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code |
Linear (1D) barcodes supported | China Post,Code 128,EAN 128,EAN 2,EAN 5,EAN-13,EAN-8,GS1 DataBar,UPC-A,UPC-E |
Pitch reading angle | -52 - 52 ° |
Sensor type | Laser |
Yaw reading angle | -52 - 52 ° |
Tilt reading angle | 0 - 360 ° |
Light levels (direct sunlight) | 0 - 100000 lx |
Wavelength | 630 nm |
Optical sensor resolution (W x H) | 1280 x 800 pixels |
Conexiune
Standard interfaces RS-232,USB Connectivity technology Wired & Wireless Operating frequency 433 MHz
Performanță
Product colour Black,Yellow Display diagonal 1.8 " International Protection (IP) code IP65, IP67 LED indicators Yes Protection features Dirt resistant,Drop proof,Dust resistant,Electrostatic Discharge (ESD) protection,Water resistant Built-in display Yes Buzzer Yes Keys quantity 4 keys Print contrast 15 % Display technology OLED Vibration function Yes
Managementul energiei
Input voltage 5 V Power source type Battery Battery technology Lithium-Ion (Li-Ion) Battery capacity 3350 mAh Power consumption 480 mA Number of reads per charge 80000 Charging time 3.2 h Power consumption (typical) 15 W Number of batteries supported 1 Battery voltage 3.7 V AC adapter output voltage 5 V
Greutate şi dimensiuni
Width 79 mm Depth 140 mm Height 149 mm Weight 445 g
Conditii de mediu
Operating temperature (T-T) -20 - 50 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 0 - 95 %
Detalii tehnice
Sustainability certificates REACH,RoHS
Date logistice
Harmonized System (HS) code 84716070
