Descriere
Scanare |
| Scanner type | 1D |
| Type | Handheld bar code reader |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Linear (1D) barcodes supported | Codabar,Code 32,Code 39,Code 93,EAN 2,EAN 5,EAN-13,GS1 DataBar Expanded,GS1 DataBar Omnidirectional,Interleaved 2 of 5,U.P.C. |
| Pitch reading angle | -75 - 75 ° |
| Sensor type | LED |
| Yaw reading angle | -70 - 70 ° |
| Tilt reading angle | -45 - 45 ° |
Conexiune
Connectivity technology Wired & Wireless Wireless range 50 m Operating frequency 433 MHz
Performanță
Product colour Black,Yellow Display resolution 48 x 132 pixels International Protection (IP) code IP65 LED indicators Yes Protection features Shock resistant Built-in display Yes Keys quantity 4 keys Backlight display Yes
Managementul energiei
Input voltage 10 - 30 V Power source type Battery Battery technology Lithium-Ion (Li-Ion) Battery capacity 2150 mAh Power consumption 500 mA Number of reads per charge 50000 Battery life 4 h
Greutate şi dimensiuni
Width 212 mm Depth 110 mm Height 74 mm Weight 435 g Base dimensions 240 x 108 x 95 mm
Datele de ambalare
Cables included No
Conditii de mediu
Operating temperature (T-T) -20 - 50 °C Storage temperature (T-T) -40 - 70 °C Operating relative humidity (H-H) 0 - 95 %
Detalii tehnice
Sustainability certificates RoHS
Date logistice
Harmonized System (HS) code 84716070
