Procesor
Processor cores	4
Processor family	Intel® Xeon® E3 v6
Processor model	E3-1220 v6
Processor cache	8 MB
Processor threads	4
Thermal Design Power (TDP)	72 W
Processor socket	LGA 1151 (Socket H4)
Processor operating modes	64-bit
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor boost frequency	3.5 GHz
Processor codename	Kaby Lake
Stepping	B0
Processor manufacturer	Intel
Bus type	DMI3
System bus rate	8 GT/s
Memory bandwidth supported by processor (max)	37.5 GB/s
Processor code	SR329
Processor base frequency	3 GHz
Component for	Server/Workstation
Cooler included	No
Processor series	Intel Xeon E3-1200 v6
Box	No
Processor ARK ID	97470
VID Voltage Range	0.55 - 1.52 V

Memorie

Memory types supported by processor DDR4-SDRAM,DDR3L-SDRAM Memory clock speeds supported by processor 1866,2133 MHz Maximum internal memory supported by processor 64 GB ECC Yes Memory channels Dual-channel

Grafică

On-board graphics card No On-board graphics card 4K support No

Caracteristici

Maximum number of PCI Express lanes 16 Scalability 1S Embedded options available No Supported instruction sets SSE4.1,SSE4.2,AVX 2.0 Execute Disable Bit Yes Idle States Yes Thermal Monitoring Technologies Yes PCI Express configurations 1x16,2x8,1x8+2x4 PCI Express slots version 3.0 Market segment Server CPU configuration (max) 1 Export Control Classification Number (ECCN) 5A992C Commodity Classification Automated Tracking System (CCATS) G077159 PCI Express CEM revision 3.0

Caracteristici speciale procesor

Conflict-Free processor Yes Intel Virtualization Technology (VT-x) Yes Intel 64 Yes Intel Trusted Execution Technology Yes Enhanced Intel SpeedStep Technology Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel TSX-NI Yes Intel Software Guard Extensions (Intel SGX) Yes Intel Enhanced Halt State Yes Intel Clear Video Technology No Intel TSX-NI version 1.00 Intel Secure Key Technology version 1.00 Intel® Turbo Boost Technology 2.0 Intel® Hyper Threading Technology (Intel® HT Technology) No Intel® AES New Instructions (Intel® AES-NI) Yes Intel® Secure Key Yes Intel® OS Guard Yes Intel® vPro™ Platform Eligibility Yes Intel® Optane™ Memory Ready Yes Intel® Transactional Synchronization Extensions Yes Intel® Boot Guard Yes Intel® Clear Video HD Technology (Intel® CVT HD) No Intel® Quick Sync Video Technology No Intel® Turbo Boost Technology 2.0 frequency 3.5 GHz Intel® InTru™ 3D Technology No Intel® Memory Protection Extensions (Intel® MPX) Yes Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) No

Detalii tehnice

Product type Processor Status Launched Launch date Q1''17 Supported memory types DDR4-SDRAM,DDR3L-SDRAM Processor cache 8192 KB Product family Intel Xeon Processor E3 v6 Family Bus speed 8 GT/s Maximum memory 64 GB Last change 63903513 Processor brand name Intel® Xeon® Bus type units GT/s Bus bandwidth 8 Maximum resolution & refresh rate (DisplayPort) N/A Maximum resolution & refresh rate (HDMI) N/A Maximum resolution & refresh rate (Integrated Flat Panel) N/A Maximum resolution & refresh rate (VGA) N/A Servicing status Baseline Servicing

Date logistice

Harmonized System (HS) code 85423119

Datele de ambalare

Package type Retail box

Greutate şi dimensiuni

Processor package size 37.5 x 37.5 mm

Alte caracteristici

Maximum internal memory 64 GB Maximum internal memory 65536 MB Graphics output N/A
