Descriere
Design |
Type | Single-phase |
Product colour | Black |
Rack capacity | 0U |
PDU types | Switched |
Mounting | Vertical |
Display | LCD |
On/off switch | No |
Conexiune
AC outlets quantity 24 AC outlet(s) AC outlet types C13 coupler,C19 coupler Power plug IEC 60309
Caracteristici
Certification EAC, EN 55022 class A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC part 15 class A, ICES-003, RCM, VDE Cable length 3 m Daisy chain Yes
Managementul energiei
Nominal input voltage 230, 220 - 240 V Output voltage 230 V AC input frequency 50 - 60 Hz Maximum power 3680 W Maximum current 16 A Nominal output voltage 239 V Maximum input current per phase 16 A Load capacity 3680 VA Maximum total current draw per phase 16 A
Greutate şi dimensiuni
Weight 5610 g Width 55 mm Height 1794 mm Depth 46 mm
Datele de ambalare
Package width 165 mm Package height 2002 mm Package depth 114 mm Package weight 8590 g
Conditii de mediu
Operating temperature (T-T) -5 - 45 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -25 - 65 °C Storage relative humidity (H-H) 5 - 95 % Operating altitude 0 - 3048 m Non-operating altitude 0 - 15240 m
