ADVANCED TECHNOLOGY TO DRIVE WORKLOADS

FLEXIBLE, FUTURE-READY PLATFORM

EFFICIENT AND RELIABLE BY DESIGN

DEPLOY ANYWHERE, SERVICE AND MANAGE EASILY

Powerful mono-socket compute and memory accelerate performance across both individual and virtualized business and industry workloads. Full-featured base units (with 8x 2.5-inch or 2x 3.5-inch storage drives, dual Gigabit LAN standard) to meet diverse SME storage needs.

Versatile 4x PCIe Gen4/3 slots (2x Gen4) to enable upgrades, with advanced options (RAID, networking, and graphics). Secure storage features protect data while M.2, dual microSD devices support flexible software boot and new high data rate USB ports enable the latest peripheral devices.

Designed to be good for both the business and the environment. Choose from amongst a 3.5-inch drive base unit with a value-oriented standard power supply, or the 2.5-inch drive base units which offer either a standard power supply or dual, hot-plug 500W power supplies for enhanced reliability and with high energy-efficiency.

Ultra-compact, low noise, easy to maintain, with Fujitsu’s Cool-safe^® technology, and a new dust-protection kit enabling wide-spread deployment. The server's iRMC S6 and Fujitsu Infrastructure Manager (ISM) software suite enable efficient server remote management and infrastructure control.

Chipset

Intel^® C256

Mainboard type

D3931

Product Type

Mono Socket Tower Server

Processor

Intel^® Xeon^® E-2300 processor family, Intel^® Pentium^® processor

Memory

8 GB - 128 GB, UDIMM (DDR4)

Memory slots

4

Memory protection

ECC

Drives (optional)

DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0

PCI-Express 3.0 x4

2 x Low profile

PCI-Express 4.0 x8

2 x Low profile (2x PCIe 4.0 x8 slots can be switched to 1x PCIe 4.0 x16)

Accessible drive bays

1 x 3.5/1.6-inch for backup devices, 1 x 5.25/9.5mm for DVD-RW/Blu-ray
1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.4-inch for CD-RW/DVD

Storage drive bays

3.5-inch non hot-plug or 2.5-inch hot-plug SAS/SATA or 2.5-inch NVMe drives
Max. 8x (4x + 4x) x 2.5-inch hot-plug
Max. 2 x 3.5-inch non hot-plug SATA

LAN Controller

Intel^® i210 onboard
2 x 1 Gbit/s Ethernet (RJ45)

USB ports

6 (Front: 1x USB 3.2 Gen2x2(20 Gbps) Type C, 1x USB 3.2 Gen1x1(5 Gbps) / Rear:, 2x USB 3.2 Gen2x1(10 Gbps) / Internal: 2x USB 3.2 Gen1x1(5 Gbps))

Graphics

2 (1x Display Port (Integrated processor graphics) / 1x VGA (15-pin) / can be used exclusively)

Management LAN (RJ45)

1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port

Trusted Platform Module (TPM)

TPM 2.0 module (option)

Power supply configuration

1 x standard, 1 x hot-plug, 2 x hot-plug redundant (depending on
Model)

Active power (max. configuration)

613 W

Weight

up to 11.1 kg

Floor-stand (W x D x H)

98 x 400 x 340 mm

DC Infrastructure Management

Infrastructure Manager (ISM)
Essential Edition
Advanced Edition

Operating system

http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473

Warranty period

1 year

Warranty type

Onsite warranty

Service Lifecycle

at least 5 years after shipment, for details see https://support.ts.fujitsu.com/

Service Weblink

http://www.fujitsu.com/fts/products/product-support-services/

Service Weblink

http://www.fujitsu.com/fts/products/product-support-services/

Recommended Service

24x7 Onsite Service with 4h Onsite Response Time
