Managementul energiei
Power protection features	Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Input current	9 A
Efficiency	93.8 %
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Total power	750 W
Max output current (+5Vsb)	3 A
Power Factor Correction (PFC) type	Active
Max output current (+5V)	22 A
Max output current (+3.3V)	22 A
Max output current (-12V)	0.5 A
Combined power (+3.3V)	110 W
Combined power (+5V)	110 W
Combined power (+12V)	744 W
Combined power (-12V)	6 W
Combined power (+5Vsb)	15 W
Hold time	22.6 ms
Peak power	850 W
Power factor	0.98
Max output current (+12V1)	25 A
Max output current (+12V2)	25 A
Maximum input current (@110V)	4.5 A
Maximum input current (@220V)	9 A
Max output current (+12V3)	30 A
Max output current (+12V4)	30 A

Conexiune

Motherboard power connector 20+4 pin ATX Number of SATA power connectors 12 PCI Express power connectors (6+2 pin) 4 Peripheral (Molex) power connectors (4-pin) 1 CPU power connector (4+4 pin) Yes Floppy disk drive connector No Motherboard power cable length 600 mm Cabling type Fully-Modular SATA power cable length 1050 mm ATX power connector (20+4 pin) Yes Number of PATA power connectors 3 PCI Express connector Yes PCI Express power connectors (8-pin) 1

Performanță

Certification BSMI, CB, CCC, CE, cTUVus, CU, FCC, RCM, TÜV, UKCA, Triman 80 PLUS certification 80 PLUS Titanium Purpose PC Noise level 18.8 dB Supported motherboard form factors ATX Power supply unit (PSU) form factor ATX ATX version 3.0 Bearing technology FDB EPS version 2.92 Silent mode Yes ECC Yes

Design

Product colour Black Fan diameter 135 mm Number of fans 1 fan(s) Cooling type Active Built-in display No Illumination No Fan location Top Fan speed 0 - 2100 RPM

Certificate

Waste Electrical and Electronic Equipment (WEEE) compliance Yes

Conţinutul de ambalaje

Cable tie(s) included Yes

Greutate şi dimensiuni

Depth 86 mm Width 150 mm Height 175 mm Weight 1960 g

Datele de ambalare

Package type Box Package weight 4230 g Package width 120 mm Package depth 350 mm Package height 270 mm

Detalii tehnice

Sustainability certificates ENERGY STAR,ErP,RoHS,WEEE Warranty period 10 year(s)

Date logistice

Shipping (inner) case length 504 mm Shipping (inner) case width 305 mm Shipping (inner) case height 368 mm Pallet gross weight (air) 18230 g
