Managementul energiei
Power protection features	Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Input current	10 A
Efficiency	95.4 %
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Total power	850 W
Max output current (+5Vsb)	3 A
Max output current (+5V)	24 A
Max output current (+3.3V)	24 A
Max output current (-12V)	0.5 A
Hold time	22.6 ms
Peak power	950 W
Max output current (+12V1)	30 A
Max output current (+12V2)	30 A
Maximum input current (@110V)	5 A
Maximum input current (@220V)	10 A
Max output current (+12V3)	35 A
Max output current (+12V4)	35 A

Conexiune

Motherboard power connector 20+4 pin ATX Number of SATA power connectors 12 PCI Express power connectors (6+2 pin) 4 CPU power connector (4+4 pin) Yes Motherboard power cable length 600 mm Cabling type Fully-Modular SATA power cable length 1050 mm Number of PATA power connectors 3

Performanță

Certification BSMI, CB, CCC, CE, cRUus, CU, FCC, cTUVus, RCM, TUV, UKCA, Triman Mean time between failures (MTBF) 100000 h 80 PLUS certification 80 PLUS Titanium Purpose PC Noise level 19.8 dB Supported motherboard form factors ATX,Micro ATX,Mini-ATX Power supply unit (PSU) form factor ATX ATX version 3.0 Bearing technology FDB EPS version 2.92

Design

Product colour Black Fan diameter 135 mm Number of fans 1 fan(s) Cooling type Active Built-in display No Illumination No Fan location Top Fan speed 0 - 1800 RPM

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C

Conţinutul de ambalaje

Cables included SATA Cable tie(s) included Yes

Greutate şi dimensiuni

Depth 175 mm Width 150 mm Height 86 mm Weight 1970 g

Datele de ambalare

Package type Box Package weight 4250 g Package width 120 mm Package depth 350 mm Package height 270 mm

Detalii tehnice

Sustainability certificates CB,CCC,CE,ENERGY STAR,ErP,Federal Communications Commission (FCC),RoHS,UKCA,WEEE Warranty period 10 year(s)

Date logistice

Shipping (inner) case length 504 mm Shipping (inner) case width 305 mm Shipping (inner) case height 368 mm Shipping (inner) case net weight 18330 g
