Caracteristicile managementului
Web-based management	Yes
Switch type	Managed
System event log	Yes

Conexiune

Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100) Basic switching RJ-45 Ethernet ports quantity 8

Reţea

Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Link aggregation Yes Full duplex Yes 10G support No Spanning tree protocol Yes Port mirroring Yes

Securitate

Security algorithms SNMP,SSH DHCP features DHCP server,DHCP snooping IGMP snooping Yes BPDU filtering/protection Yes Static port security Yes

Design

Product colour Black International Protection (IP) code IP30 Safety UL/CSA 60950-1, EN 60950-1, IEC 60950-1, NOM - NOM-019-SCF1, UL/CSA/IEC/EN 61010-2-201, CE Electromagnetic compatibility FCC 47 CFR 15 A, EN 55022/CISPR 22 A, EN 55016-1-1, -1-4, -2-3 AVCCI A, RoHS, AS/NZS CISPR 22 A, AS/NZS CISPR 24, CISPR11 Class A, CISPR22 A, ICES 003 A, KCC, CE, RCM, EAC, Anatel, NAL, IEC/EN/EN61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-9, IEC/EN 61000-4-29 DIN rail mounting Yes

Performanță

Mean time between failures (MTBF) 374052 h Internal memory 128 MB Flash memory 160 MB Memory type DDR2-SDRAM

Managementul energiei

Power consumption (typical) 5.3 W Power consumption (max) 205.2 W DC input voltage 12 - 24 V

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Operating temperature (T-T) -20 - 70 °C Operating relative humidity (H-H) 5 - 95 % Storage temperature (T-T) -40 - 85 °C

Greutate şi dimensiuni

Width 45.7 mm Depth 115 mm Height 127 mm Weight 570 g

Date logistice

Harmonized System (HS) code 85176990
