Caracteristicile managementului
Quality of Service (QoS) support	Yes
Switch type	Managed
Switch layer	L2/L3
MIB support	Yes

Conexiune

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 24

Reţea

Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ap,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3z VLAN support Yes Number of VLANs 4000 Link aggregation Yes Full duplex Yes Virtual LAN features VLAN Identifier ( VLAN ID) Spanning tree protocol Yes Multiprotocol Label Switching (MPLS) Yes Zero Touch Provisioning (ZTP) Yes

Transmisie de date

Jumbo frames support Yes MAC address table 32000 entries Switching capacity 256 Gbit/s Forwarding rate 190.48 Mpps Jumbo frames 9198 Packet buffer memory 16 MB

Securitate

Access Control List (ACL) Yes DHCP features DHCP snooping

Specificații (mod transmitere) multicast

Multicast support Yes

Protocoale

Routing protocols EIGRP,HSRP,OSPF,RIP-2

Design

Product colour Grey Rack mounting Yes LED indicators Yes Stackable Yes Safety UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking

Performanță

Mean time between failures (MTBF) 27770 h Firmware upgradeable Yes Internal memory 8192 MB Flash memory 16384 MB

Managementul energiei

Power consumption (typical) 715 W

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 48 Power over Ethernet (PoE) Yes

Conditii de mediu

Operating temperature (T-T) -5 - 40 °C Operating relative humidity (H-H) 5 - 90 % Storage temperature (T-T) -40 - 70 °C Operating altitude 0 - 3000 m

Greutate şi dimensiuni

Width 445 mm Depth 445 mm Height 44 mm
