Caracteristicile managementului
Switch type	Unmanaged

Conexiune

Basic switching RJ-45 Ethernet ports quantity 8 Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100) Fast Ethernet (copper) ports quantity 8

Reţea

Networking standards IEEE 802.3,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x Auto MDI/MDI-X Yes 10G support No Flow control support Yes Full duplex Yes Half duplex Yes

Transmisie de date

MAC address table 1000 entries Maximum data transfer rate 1 Gbit/s Switching capacity 1.6 Gbit/s Packet buffer memory 0.09 MB Store-and-forward Yes

Design

Product colour Black Certification FCC, CE, VCCI LED indicators LAN,PoE,Power Safety LVD

Detalii tehnice

Shipping (inner) case length 375 mm Shipping (inner) case height 430 mm Shipping (inner) case net weight 11900 g Master (outer) cases per pallet (air) 48 pc(s) Products per pallet (sea) 480 pc(s) Pallet gross weight (sea) 628450 g Pallet gross width 1200 mm Pallet height (sea) 1915 mm Pallet gross length 1100 mm Master (outer) cases per pallet (sea) 48 pc(s) Pallet gross weight (air) 628450 g Products per shipping (inner) case 10 pc(s) Pallet height (air) 1915 mm Products per pallet (air) 480 pc(s) Shipping (inner) case width 265 mm Shipping (inner) case gross weight 12650 g

Managementul energiei

Input current 1.25 A Input voltage 51 V Power source DC

Curent pe cablu net (PoE)

Power over Ethernet (PoE) ports quantity 4 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 52 W Power over Ethernet (PoE) power per port 15 W

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 95 % Storage temperature (T-T) -10 - 70 °C Storage relative humidity (H-H) 5 - 90 %

Greutate şi dimensiuni

Width 170.18 mm Height 27.94 mm Depth 99.06 mm Weight 454 g

Datele de ambalare

Package weight 1190 g Package width 208 mm Package depth 250 mm Package height 68 mm

Date logistice

Harmonized System (HS) code 85176990
