Caracteristicile managementului
Quality of Service (QoS) support	Yes
Switch type	Unmanaged

Conexiune

Gigabit Ethernet (copper) ports quantity 5 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 5 Power connector DC-in jack

Reţea

Auto-negotiation Yes Networking standards IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x Full duplex Yes Copper ethernet cabling technology 10BASE-T,100BASE-TX,1000BASE-T Auto MDI/MDI-X Yes 10G support No MAC address auto-learning supported Yes

Transmisie de date

MAC address table 2000 entries Switching capacity 10 Gbit/s Forwarding rate 7.44 Mpps Store-and-forward Yes

Securitate

Packet filtering 7.44 Mpps

Design

Product colour Black Rack mounting No LED indicators Activity,Link,PoE,Power,Speed,Status Housing material Metal Certification CE, BSMI, FCC , VCCI, RCM, cUL, CB, LVD, BSMI Wall mountable Yes

Performanță

Plug and Play Yes Buffer size 64 KB

Managementul energiei

Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 60 W Power over Ethernet (PoE) power per port 30 W Power over Ethernet (PoE) ports quantity 4

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -10 - 70 °C Storage relative humidity (H-H) 0 - 95 %

Greutate şi dimensiuni

Width 100 mm Depth 98 mm Height 28 mm Weight 260 g
