Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2
System event log	Yes

Conexiune

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 16

Reţea

Flow control support Yes Ethernet LAN data rates 10,100,1000 Mbit/s Auto-negotiation Yes Networking standards IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Number of VLANs 128 Link aggregation Yes Full duplex Yes Copper ethernet cabling technology 10BASE-T,10BASE-TX,1000BASE-T Auto MDI/MDI-X Yes Virtual LAN features Port-based VLAN,Voice VLAN 10G support No Spanning tree protocol Yes Broadcast storm control Yes Rate limiting Yes Port mirroring Yes Head-of-line (HOL) blocking Yes

Transmisie de date

Jumbo frames support Yes MAC address table 8000 entries Switching capacity 32 Gbit/s Forwarding rate 23.81 Mpps Jumbo frames 9216 Packet buffer memory 4.1 MB Number of queues 4 Store-and-forward Yes

Securitate

Security algorithms SNMP,SSL/TLS DHCP features DHCP client IGMP snooping Yes Queue scheduling algorithms SPQ,Weighted Round Robin (WRR)

Specificații (mod transmitere) multicast

Multicast support Yes

Design

Product colour Black Rack mounting Yes LED indicators Yes Certification EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC

Performanță

Mean time between failures (MTBF) 710519 h Flash memory 16 MB Memory type DRAM Built-in processor Yes Processor frequency 125 MHz Fanless Yes

Managementul energiei

AC input frequency 50/60 Hz AC input voltage 100 - 240 V Power consumption (max) 10.1 W Power source AC

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Heat dissipation 34.46 BTU/h Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -40 - 70 °C Operating altitude 0 - 2000 m Storage relative humidity (H-H) 0 - 95 %

Greutate şi dimensiuni

Width 280 mm Depth 180 mm Height 44 mm Weight 1270 g
