Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2

Conexiune

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 24

Reţea

Flow control support Yes Ethernet LAN data rates 10,100,1000 Mbit/s Auto-negotiation Yes Networking standards IEEE 802.1Q,IEEE 802.1p,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3x VLAN support Yes Number of VLANs 128 Link aggregation Yes Full duplex Yes Auto MDI/MDI-X Yes Virtual LAN features Port-based VLAN 10G support No Spanning tree protocol Yes Broadcast storm control Yes Rate limiting Yes Port mirroring Yes Head-of-line (HOL) blocking Yes Half duplex Yes

Transmisie de date

Jumbo frames support Yes MAC address table 8000 entries Switching capacity 48 Gbit/s Forwarding rate 35.71 Mpps Jumbo frames 9216 Packet buffer memory 4.1 MB

Securitate

IGMP snooping Yes Loop protection Yes

Design

Product colour Black,Grey Rack mounting Yes LED indicators Yes Certification FCC, CE, VCCI, C-Tick, BSMI, CCC Form factor 1U

Performanță

Mean time between failures (MTBF) 424762 h Flash memory 16 MB

Managementul energiei

AC input frequency 50/60 Hz AC input voltage 100 - 240 V Power consumption (max) 15.9 W Number of power supply units 1 Power source AC Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Heat dissipation 54.3 BTU/h Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -40 - 70 °C Storage relative humidity (H-H) 0 - 95 %

Greutate şi dimensiuni

Width 280 mm Depth 180 mm Height 44 mm Weight 1320 g

Sustenabilitate

Sustainability certificates BSMI,CB,CCC,cUL Sustainability compliance Yes
