Descriere
Conexiune |
Connectivity technology | Wired |
Fiber optic connector | SFP |
Fiber ports quantity | 1 |
Interface | Fiber |
Host interface | USB |
USB version | 3.2 Gen 1 (3.1 Gen 1) |
Reţea
Jumbo frames support Yes Full duplex Yes Networking standards IEEE 802.1Q,IEEE 802.3z Maximum data transfer rate 1000 Mbit/s Fiber ethernet cabling technology 1000BASE-SX,1000BASE‑LX Jumbo frames 9000 VLAN tagging Yes Wake-on-LAN ready Yes
Design
Product colour Black Internal No LED indicators Activity,Link,Power Plug and Play Yes Chipset Realtek - RTL8153-VB-CG, Microsemi - VSC8211XVW
Managementul energiei
USB powered Yes
Cerinţe de sistem
Windows operating systems supported Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 Linux operating systems supported Yes Mac operating systems supported Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.9 Mavericks,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Mac OS X 13.0 Ventura Server operating systems supported Windows Server 2008,Windows Server 2012,Windows Server 2016,Windows Server 2019
Conditii de mediu
Operating temperature (T-T) 0 - 60 °C Operating relative humidity (H-H) 5 - 90 % Storage temperature (T-T) -10 - 70 °C
Sustenabilitate
Sustainability certificates CE,RoHS Sustainability compliance Yes
Greutate şi dimensiuni
Weight 106 g Width 141 mm Depth 170 mm Height 20 mm
Datele de ambalare
Package depth 265 mm Package width 170 mm Package height 30 mm
Date logistice
Harmonized System (HS) code 85176990 Master (outer) case width 310 mm Master (outer) case length 590 mm Master (outer) case height 355 mm Products per master (outer) case 80 pc(s)
Alte caracteristici
Cable length 0.195 m Housing material Plastic Quick start guide Yes
