Descriere
Performanță |
Supported video modes | 720p,1080p |
Video formats supported | H.264,M-JPEG,YUV |
Signal-to-Noise Ratio (SNR) | 50 dB |
Plug and Play | Yes |
Maximum frame rate | 30 fps |
Maximum video resolution | 1920 x 1080 pixels |
Operating voltage | 5 V |
Power consumption (typical) | 5 W |
Megapixel (approx.) | 2.07 MP |
Auto focus | Yes |
Face tracking | No |
Resolution at capture speed | 640x480@30fps,1280x720@30fps,1920x1080@30fps |
Maximum image resolution | 1920 x 1080 pixels |
Operating current | 0.5 A |
Camera HD type | Full HD |
Design
Product colour Black Interface USB Mounting type Clip/Stand Sensor type CMOS Optical sensor size 1/2.9 " Built-in microphone Yes Cable length 1.5 m Built-in flash No Housing material Acrylonitrile butadiene styrene (ABS),Polycarbonate (PC) Image stabilizer No
Software
Windows operating systems supported Windows 10,Windows 8.1,Y Mac operating systems supported Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.15.3 Catalina,Mac OS X 10.5 Leopard,Mac OS X 10.6 Snow Leopard,Mac OS X 10.7 Lion,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Y Other operating systems supported ChromeOS Linux operating systems supported Yes
Conditii de mediu
Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 90 % Storage temperature (T-T) -20 - 60 °C Storage relative humidity (H-H) 0 - 90 %
Greutate şi dimensiuni
Depth 53.5 mm Width 102 mm Height 53 mm Weight 120 g
Datele de ambalare
Package weight 210 g Package height 60 mm Package width 155 mm Package depth 95 mm Quantity 1 Package type Box
Conţinutul de ambalaje
Quick installation guide Yes Box contents 1 x USB™ HD Webcam with 360° rotation (Model: JVCU100), 1 x Quick Installation Guide
Cerinţe de sistem
Minimum system requirements Available USB™ Type-A port, Windows® 10, macOS® with UVC support, Chrome OS™ with UVC support, Operating systems compliant with standard UVC 1.0/1.1 & UAC support
Date logistice
Master (outer) case width 230 mm Master (outer) case height 190 mm Master (outer) case length 435 mm Master (outer) case gross weight 3040 g Master (outer) case GTIN (EAN/UPC) 24712795085574 Shipping (inner) case gross weight 740 g Country of origin Taiwan Shipping (inner) case width 103 mm Shipping (inner) case length 207 mm Shipping (inner) case height 165 mm Products per shipping (inner) case 3 pc(s) Quantity per box 1 pc(s) Products per master (outer) case 12 pc(s) Commodity Classification Automated Tracking System (CCATS) 8525.50.0000 Export Control Classification Number (ECCN) EAR99
Detalii tehnice
Warranty period 2 year(s)
