Procesor
Processor model	i7-13700HX
Processor cores	16
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Thermal Design Power (TDP)	157 W
Processor threads	24
Built-in processor	Yes
Processor cache	30 MB
Processor generation	13th gen Intel® Core™ i7
Processor frequency	2.1 GHz
Efficient cores	8
Efficient-core boost frequency	3.7 GHz
Performance cores	8
Performance-core boost frequency	5 GHz

Memorie

Maximum internal memory 64 GB Supported memory types DDR5-SDRAM Number of memory slots 2 Memory channels Dual-channel Memory slots type SO-DIMM Supported memory clock speeds 4800 MHz

Medii de stocare

Number of storage drives supported 2 Supported storage drive types SSD Storage drive sizes supported M.2 " SSD form factor M.2 Storage drive interface PCI Express Card reader integrated Yes Compatible memory cards SD,SDHC,SDXC

Grafică

On-board graphics card Yes Discrete graphics card model NVIDIA GeForce RTX 4070 Graphics card family NVIDIA Number of displays supported 3 Maximum graphics card memory 8192 MB Maximum resolution 7680 x 4320 pixels Graphics card memory type GDDR6

Reţea

Wi-Fi Yes Ethernet LAN Yes Bluetooth Yes Wi-Fi standards Wi-Fi 6 (802.11ax) Top Wi-Fi standard Wi-Fi 6 (802.11ax) Bluetooth version 5.2

Conexiune

HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 2 HDMI version 2.1 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 5 DisplayPorts quantity 2 DC-in jack Yes DisplayPort version 1.4 Microphone in Yes Headphone outputs 1 Thunderbolt 4 ports quantity 1

Design

Product type Mini PC (<= 3L) barebone Product colour Black Cable lock slot Yes Cable lock slot type Kensington On/off switch Yes Cooling type Active LED indicators HDD,Power,Wi-Fi

Performanță

Audio output channels 8.0 channels

Software

Windows operating systems supported Windows 11

Managementul energiei

Power supply 330 W AC adapter output voltage 19.5 V Power supply type External AC adapter Number of power supply units 1

Greutate şi dimensiuni

Width 210 mm Depth 203 mm Height 62.2 mm

Conţinutul de ambalaje

Drivers included Yes Power cord included Yes AC adapter included Yes Quick start guide Yes
