Descriere
Conexiune |
Host interface | PCIe |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Output interface | USB 3.2 Gen 2 (3.1 Gen 2) |
Expansion card standard | PCIe 3.0 |
Expansion card form factor | Full-height / Low-profile |
Design
Product colour Red Internal Yes Mean time between failures (MTBF) 2684396 h
Caracteristici
UASP support Yes Chipset ASMedia - ASM3142 Data transfer rate (max) 10 Gbit/s
Conditii de mediu
Operating temperature (T-T) 5 - 50 °C Storage temperature (T-T) -20 - 85 °C Operating relative humidity (H-H) 20 - 80 %
Cerinţe de sistem
Windows operating systems supported Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 Mac operating systems supported Mac OS X 10.13 High Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Mac OS X 13.0 Ventura Linux operating systems supported Yes Server operating systems supported Windows Server 2008 R2,Windows Server 2012,Windows Server 2016,Windows Server 2019
Detalii tehnice
Sustainability certificates CE,RoHS Sustainability compliance Yes
Greutate şi dimensiuni
Weight 48 g Width 81 mm Depth 120 mm Height 19 mm
Datele de ambalare
Package width 170 mm Package depth 142 mm Package weight 123 g Package height 30 mm Quick installation guide Yes Mounting brackets included Yes
Date logistice
Master (outer) case width 370 mm Master (outer) case height 500 mm Master (outer) case length 365 mm Products per master (outer) case 60 pc(s) Harmonized System (HS) code 84733020
