Descriere
Caracteristici |
Surge protection | Yes |
Surge energy rating | 600 J |
UPS topology | Double-conversion (Online) |
Noise level | 50 dB |
Output power capacity | 3 kVA |
Input frequency | 40/70 Hz |
Output power | 2400 W |
Input operation voltage (max) | 285 V |
Input operation voltage (min) | 110 V |
Output operation voltage (max) | 240 V |
Output operation voltage (min) | 220 V |
Efficiency | 88 % |
Waveform | Pure sine |
Output frequency | 50/60 Hz |
Crest factor | 3:1 |
Output voltage regulation | 3 % |
Power source type | AC |
Detachable power cord | Yes |
Conexiune
AC outlets quantity 7 AC outlet(s) AC outlet types C13 coupler,C19 coupler USB port Yes RS-232 ports 1 Serial interface Yes USB port type USB Type-B
Baterie
Battery technology Sealed Lead Acid (VRLA) Battery voltage 72 V Battery recharge time 5.5 h Battery life (max) 5 year(s) Charging current 4 A
Design
Product colour Black Form factor Rackmount Rack capacity 4U Cable length 1.5 m International Protection (IP) code IP20 Display type LCD
Conditii de mediu
Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -20 - 50 °C Storage relative humidity (H-H) 0 - 95 % Operating altitude 0 - 3000 m Non-operating altitude 0 - 15000 m
Greutate şi dimensiuni
Weight 9500 g Width 86 mm Depth 438 mm Height 432 mm Package weight 1800 g Package width 554 mm Package depth 240 mm Package height 700 mm
Datele de ambalare
Cables included Input power cable,Output power cable,RS-232,USB cable Manual Yes Rack mount kit Yes
Date logistice
Harmonized System (HS) code 85078000
