Performanță
Connectivity technology	Wired
Type	IP security camera
Placement supported	Indoor
Certification	55032 A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC 15 B A, ICES-003 A, VCCI A, RCM AS/NZS CISPR 32 A, KCC KN32 A, KN35 IEC/EN/UL 60950-1 IEC/EN 62368–1 IEC/EN 60529 IP52, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78 NIST SP500-267 EN 60950-1, GS, UL, cUL, CE, FCC, VCCI, CB, KCC, UL-AR
PTZ control	Yes
Day/night mode	Yes
Languages support	CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN,KOR,POR,RUS
Number of languages	11
Infrared (IR) cut-off filter	Yes

Design

Product colour White Form factor Dome Mounting type Ceiling International Protection (IP) code IP52 Housing material Aluminium

Aparat de fotografiat

Camera shutter speed 1/11000 - 1/3 s Minimum illumination 0.03 lx Tilt angle range 0 - 180 ° Pan range 0 - 360 ° Camera tilt control Yes Camera pan control Yes Pan speed 450 °/sec Tilt speed 450 °/sec Lens viewing angle, vertical 39.1 ° Lens viewing angle, horizontal 65.1 °

Senzor de imagine

Sensor type CMOS Optical sensor size 1/2.8 " Progressive scan Yes Number of sensors 1

Sistem de lentile

Maximum aperture number 4.95 Focal length range 4.25 - 170 mm Zoom capability Yes Number of lenses 1 Digital zoom 12 x Optical zoom 40 x Minimum aperture number 1.6 Auto focus Yes

Video

Maximum resolution 1920 x 1080 pixels Video compression formats AVC,H.264,H.265,HEVC,M-JPEG,MPEG4 Bit rate control Variable Bit Rate (VBR)

Audio

Audio formats supported AAC Voice codecs G.711,G.726,PCM

Reţea

Ethernet LAN Yes Supported network protocols IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP, LLDP Networking standards IEEE 802.1x,IEEE 802.3at Ethernet interface type Fast Ethernet Wi-Fi No Quality of Service (QoS) support Yes Bluetooth No

Medii de stocare

Compatible memory cards SD,SDHC,SDXC Card reader integrated Yes Flash memory 512 MB Internal memory 1024 MB Built-in HDD No

Conexiune

Ethernet LAN (RJ-45) ports 1

Securitate

IP address filtering Yes HTTPS encryption Yes Video motion detection Yes Password protection Yes Security algorithms EAP-TLS

Managementul energiei

Power source type AC,PoE Power consumption (max) 22.4 W AC input voltage 100 - 240 V

Conditii de mediu

Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 10 - 85 % Storage temperature (T-T) -40 - 65 °C

Greutate şi dimensiuni

Weight 2850 g Height 240 mm Diameter 198 mm

Conţinutul de ambalaje

Number of cameras 1

Date logistice

Harmonized System (HS) code 85258900
