Descriere
Caracteristicile managementului |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Switch type | Managed |
Switch layer | L2 |
MIB support | Yes |
ARP inspection | Yes |
Traffic classification | Yes |
Configuring Location Settings (CLI) | Yes |
Conexiune
USB 2.0 ports quantity 1 Combo SFP ports quantity 2 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 8
Reţea
Ethernet LAN data rates 10,100,1000 Mbit/s Auto-negotiation Yes Networking standards IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3u,IEEE 802.3z VLAN support Yes Link aggregation Yes Full duplex Yes Auto MDI/MDI-X Yes Spanning tree protocol Yes Broadcast storm control Yes
Transmisie de date
Jumbo frames support Yes MAC address table 15360 entries Switching capacity 20 Gbit/s Forwarding rate 10000 Mpps Static route Yes Jumbo frames 10240
Securitate
Access Control List (ACL) Yes DHCP features DHCP snooping IGMP snooping Yes SSH/SSL support Yes BPDU filtering/protection Yes Authentication Web-based authentication Loop protection Yes Authentication type RADIUS IGMP entries 1024
Specificații (mod transmitere) multicast
Multicast support Yes IPv4 multicast entries 1024
Protocoale
Management protocols SNMP
Design
Product colour Grey Country of origin China Market segment Business
Performanță
Mean time between failures (MTBF) 2171669 h Processor model ARM7 Internal memory 512 MB Flash memory 256 MB Memory type DRAM Built-in processor Yes Processor frequency 800 MHz
Detalii tehnice
Products per shipping (inner) case 1 pc(s)
Managementul energiei
AC input frequency 50 - 60 Hz AC input voltage 110 - 240 V Power consumption (typical) 14.2 W Power consumption (max) 14.9 W Input current 0.22 A Power plug type Type C Power supply included Yes
Conditii de mediu
Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 5 - 90 % Storage temperature (T-T) -25 - 70 °C Operating altitude 0 - 3000 m Storage relative humidity (H-H) 5 - 95 % Non-operating altitude 0 - 4500 m
Datele de ambalare
Package weight 2594.1 g Package width 309.626 mm Package depth 349.25 mm Package height 160.274 mm
Date logistice
Harmonized System (HS) code 85176990 Quantity per pack 1 pc(s) Products per master (outer) case 1 pc(s)
Alte caracteristici
Dimensions (W x D x H) (imperial) 10.56 x 7.28 x 1.73 "
